15 Filling Heads Fully Automatic Suppository Filling Sealing Production Line

Performance:

SINOTECH-15S automatic suppository /filling production line has a stable and

efficient manufacturing process, filling, freezing, sealing and other production processes to complete the whole process, and the production capacity is 18,000-20,000grain/hour.

Process flow

It will be rolled into the forming area by the clamping mechanism. The mold will be heated by the preheating mold, the mold, the mold,the blow mold and the bubble forming.

The triangle knife will be cutting suppository top edge (cutting edge).

Filling

And one-time molding suppository for embeddled type filling, filling accuracy +/-2%, filling material barrel has electric heating insulation system, the top is equipped with a uniform mixing machine in order to make drugs, drug by high precision in VAT filling pump into the filling head, a drug through the other end of the cycle to restafter filling material barrel filling again next time.

Cooling design

The suppository of the whole drainage is entered into the cooling box, and the cooling box is equipped with a cold water unit. The cooling aircools the suppository in the cooling box through the condenser in the cooling box.

Shearing

After being cooled, the solid suppository entersthe sealing zone: preheating mold (preheating), sealing mould (seal), marking mould (batch number),hob (top), counting shear.
