7 Filling Heads Continuously Automatic Suppository Production Line

7 Filling Heads Continuously Automatic Suppository Production Line

Technical Performance Introduction of 7 Filling Heads Continuously Automatic Suppository Production Line


Working principle of the machine:

The SINOTECH-7L automatic suppository filling production line has a stable and efficient manufacturing process, filling, freezing, sealing and other production processes to complete the whole process, and the production capacity is 8000-12000 pcs per hour.


Specifications of 7 Filling Heads Continuously Automatic Suppository Production Line


ModelSINOTECH -7L
Output Capacity8000-12000pcs/h
Single Dosage0.5-5ml
Dosage Allowed< ±2%
Packaging FilmPVC/PE (Thickness 0.15-0. 18mm)
Stirring Tank Capacity70L
Air Pressure≥0.6Mpa
Air Consumption1.5m3/min
Water Consumption50kg/h (recycling)
Voltage380V 50Hz 3P
Total Power7.5kw
Machine Weight2000kg
Each Distance of Suppository17.4mm

Overall Dimensions

5302mm×2120mm×1809mm (L×W×H)
Adopt Forming ShapesBullet, torpedo and other shapes
Adopt MaterialSynthetic fatty acid glycerol, glycerin gelatin, polyethylene glycol etc




Electric Parts Configuration List of 7 Filling Heads Continuously Automatic Suppository Production Line


No.

Item

Brand

1

Programmable Controller

SIEMENS

2

HIM

WEINVIEW

3

Inverter

SCHNEIDER

4

Servo Motor

SCHNEIDER

5

Low Voltage Electrical Appliances

SCHNEIDER

6

Temperature Controller

(multi-channel temperature controller)

YUDIAN

7

Electromagnetic Valve Gas Source Treatment

TAIWAN AIRTAC

8

Photoelectric Switch

PANASONIC

9

Proximity Switch

SUODILONG

10

Alarm Device (Alarm Lamp)

MADE IN CHINA
